AMD Ryzen 7000 Series processors, emphasizing their cutting-edge performance and features for gamers and creators:
Introduces the new era of performance with the AMD Ryzen 7000 Series, highlighting their speed and power for gaming and creative workflows.
Describes the gaming capabilities of the AMD Ryzen 7000 Series processors, focusing on their high-performance "Zen 4" cores, up to 16 cores, 32 threads, and boost clocks of up to 5.7GHz.
Highlights the advanced technologies integrated into the processors, such as PCIe 5.0 storage support, WiFi 6E, and AMD EXPO™ technology, aimed at enhancing connectivity and performance.
Discusses bleeding-edge technologies supporting the processors, including AMD EXPO™ Technology for memory overclocking and DDR5 memory support for accelerated gaming.
Teases the future of Ryzen processors with "Zen 4" performance and AMD Socket AM5 motherboards, featuring high-speed DDR5 memory and PCIe 5.0 support.
attribute | value |
|---|
Name | AMD Ryzen™ 5 7600X |
Family | Ryzen |
Series | Ryzen 7000 Series |
Form Factor | Desktops, Boxed Processor |
Market Segment | Enthusiast Desktop |
AMD PRO Technologies | No |
Regional Availability | Global |
Former Codename | Raphael AM5 |
Processor Architecture | Zen 4 |
# of CPU Cores | 6 |
Multithreading (SMT) | Yes |
# of Threads | 12 |
Max. Boost Clock | Up to 5.3 GHz |
Base Clock | 4.7 GHz |
L1 Cache | 384 KB |
L2 Cache | 6 MB |
L3 Cache | 32 MB |
Default TDP | 105W |
Processor Technology for CPU Cores | TSMC 5nm FinFET |
Processor Technology for I/O Die | TSMC 6nm FinFET |
CPU Compute Die (CCD) Size | 71mm² |
I/O Die (IOD) Size | 122mm² |
Package Die Count | 2 |
Unlocked for Overclocking | Yes |
AMD EXPO™ Memory Overclocking | Yes |
Precision Boost Overdrive | Yes |
Curve Optimizer Voltage Offsets | Yes |
AMD Ryzen™ Master Support | Yes |
CPU Socket | AM5 |
Supporting Chipsets | A620, X670E, X670, B650E, B650, X870E, X870, B840, B850 |
CPU Boost Technology | Precision Boost 2 |
Instruction Set | x86-64 |
Supported Extensions | AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX-plus, SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3 |
Thermal Solution (PIB) | Not Included |
Recommended Cooler | Premium air cooler recommended for optimal performance |
Max. Operating Temperature (Tjmax) | 95°C |
Launch Date | 09/27/2022 |
OS Support | Windows 11/10 64-bit, RHEL x86 64-Bit, Ubuntu x86 64-Bit |
Connectivity |
- Native USB 3.2 Gen 2 (10Gbps) | 4 |
- Native USB 3.2 Gen 1 (5Gbps) | 0 |
- Native USB 2.0 (480Mbps) | 1 |
- Native SATA Ports | 0 |
PCI Express® Version | PCIe® 5.0 |
Native PCIe® Lanes (Total/Usable) | 28 / 24 |
Additional PCIe Lanes from Motherboard | X670E: 12x Gen4, X670: 12x Gen4, B650E: 8x Gen4, B650: 8x Gen4 |
NVMe Support | Boot, RAID0, RAID1, RAID10 |
System Memory Type | DDR5 |
Memory Channels | 2 |
Max. Memory | 128 GB |
System Memory Subtype | UDIMM |
Max Memory Speed | 2x1R DDR5-5200, 2x2R DDR5-5200, 4x1R DDR5-3600, 4x2R DDR5-3600 |
ECC Support | Yes (Requires motherboard support) |
Graphics Capabilities |
- Graphics Model | AMD Radeon™ Graphics |
- Graphics Core Count | 2 |
- Graphics Frequency | 2200 MHz |
USB Type-C® DisplayPort™ Alt Mode | Yes |
Product IDs |
- Product ID Boxed | 100-100000593WOF |
- Product ID Tray | 100-000000593 |
Key Features | AMD EXPO™ Technology, AMD Ryzen™ Technologies |
Warranty | 3 Years |
