The world's fastest gaming desktop processor and first gaming processor with 3D stacking technology
8 Cores and 16 processing threads with AMD 3D V-Cache technology
4.5 GHz Max Boost, 100 MB cache, DDR4-3200 support
For the advanced Socket AM4 platform, can support PCIe 4.0 on X570 and B550 motherboards
Cooler not included, high-performance cooler recommended
Name | AMD Ryzen™ 7 5800X3D |
Family | Ryzen |
Series | Ryzen 5000 Series |
Form Factor | Desktops, Boxed Processor |
Market Segment | Enthusiast Desktop |
AMD PRO Technologies | No |
Regional Availability | Global, China, NA, EMEA, APJ, LATAM |
Former Codename | Vermeer |
Processor Architecture | Zen 3 |
# of CPU Cores | 8 |
Multithreading (SMT) | Yes |
# of Threads | 16 |
Max. Boost Clock | Up to 4.5 GHz |
Base Clock | 3.4 GHz |
L1 Cache | 512 KB |
L2 Cache | 4 MB |
L3 Cache | 96 MB |
Default TDP | 105W |
Processor Technology for CPU Cores | TSMC 7nm FinFET |
Processor Technology for I/O Die | 12nm (Globalfoundries) |
CPU Compute Die (CCD) Size | 74 mm² |
I/O Die (IOD) Size | 125 mm² |
Package Die Count | 1 |
CPU Socket | AM4 |
Supporting Chipsets | X570, X470, B550, B450, A520 |
CPU Boost Technology | Precision Boost 2 |
Instruction Set | x86-64 |
Supported Extensions | AES, AMD-V, AVX, AVX2, FMA3, MMX-plus, SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64 |
Thermal Solution (PIB) | Not Included |
Recommended Cooler | Liquid cooler recommended for optimal performance |
Max. Operating Temperature (Tjmax) | 90°C |
OS Support | Windows 11 - 64-Bit Edition, Windows 10 - 64-Bit Edition, RHEL x86 64-Bit, Ubuntu x86 64-Bit |
Connectivity |
Native USB 3.2 Gen 2 (10Gbps) | 4 |
Native USB 3.2 Gen 1 (5Gbps) | 0 |
Native USB 2.0 (480Mbps) | 0 |
Native SATA Ports | 2 |
PCI Express® Version | PCIe® 4.0 |
Native PCIe® Lanes (Total/Usable) | 24 / 20 |
Additional Usable PCIe Lanes from Motherboard | X570: 16x Gen 4; X470: 2x Gen 3, 8x Gen 2 |
NVMe Support | Boot, RAID0, RAID1, RAID10 |
System Memory Type | DDR4 |
Memory Channels | 2 |
Max. Memory | 128 GB |
System Memory Subtype | UDIMM |
Max Memory Speed | 2x1R DDR4-3200, 2x2R DDR4-3200, 4x1R DDR4-2933, 4x2R DDR4-2667 |
ECC Support | Yes (Requires motherboard support) |
Graphics Capabilities |
Graphics Model | Discrete Graphics Card Required |
Key Features |
Supported Technologies | AMD 3D V-Cache™ Technology, Windows® 11 Gaming, AMD Ryzen™ VR-Ready Premium |
Warranty | 3 Years |
