AMD Ryzen™ 9 9900X is a high-performance desktop processor designed for enthusiasts. Built on the cutting-edge Zen 5 architecture and crafted using TSMC's advanced 4nm process, it boasts 12 cores and 24 threads capable of reaching speeds up to 5.6 GHz. This unlocked chip supports DDR5 memory, PCIe 5.0, and offers robust overclocking capabilities through Precision Boost Overdrive and Curve Optimizer. With a generous 64MB L3 cache and integrated AMD Radeon graphics, the 9900X excels in demanding tasks like content creation, gaming, and professional applications. Its compatibility with AM5 motherboards ensures future-proof expandability. While a liquid cooler is recommended for optimal performance, this powerhouse delivers exceptional speed and efficiency for those seeking the ultimate desktop experience
Powerful Core and Thread Count: Equipped with 12 cores and 24 threads, delivering exceptional performance for demanding tasks.
Advanced Architecture: Built on the Zen 5 architecture with TSMC's 4nm process for optimal performance and power efficiency.
Robust Memory Support: Supports DDR5 memory with speeds up to DDR5-5600 for enhanced system responsiveness.
Extensive Connectivity: Offers 4 native USB 3.2 Gen 2 ports and 1 native USB 2.0 port for versatile device connections.
Supporting Chipsets : A620 , X670E , X670 , B650E , B650 , X870E , X870
Name | AMD Ryzen™ 9 9900X |
Family | Ryzen |
Series | Ryzen 9000 Series |
Form Factor | Desktops, Boxed Processor |
Market Segment | Enthusiast Desktop |
AMD PRO Technologies | No |
Regional Availability | Global |
Former Codename | Granite Ridge AM5 |
Processor Architecture | Zen 5 |
# of CPU Cores | 12 |
Multithreading (SMT) | Yes |
# of Threads | 24 |
Max. Boost Clock | Up to 5.6 GHz |
Base Clock | 4.4 GHz |
L1 Cache | 960 KB |
L2 Cache | 12 MB |
L3 Cache | 64 MB |
Default TDP | 120W |
Processor Technology for CPU Cores | TSMC 4nm FinFET |
Processor Technology for I/O Die | TSMC 6nm FinFET |
Package Die Count | 3 |
Unlocked for Overclocking | Yes |
AMD EXPO™ Memory Overclocking Technology | Yes |
Precision Boost Overdrive | Yes |
Curve Optimizer Voltage Offsets | Yes |
AMD Ryzen™ Master Support | Yes |
CPU Socket | AM5 |
Supporting Chipsets | A620, X670E, X670, B650E, B650, X870E, X870, B840, B850 |
CPU Boost Technology | Precision Boost 2 |
Instruction Set | x86-64 |
Supported Extensions | AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX-plus, SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64 |
Thermal Solution (PIB) | Not Included |
Recommended Cooler | Liquid cooler recommended for optimal performance |
Max. Operating Temperature (Tjmax) | 95°C |
Launch Date | 08/15/2024 |
OS Support | Windows 11 - 64-Bit, Windows 10 - 64-Bit, RHEL x86 64-Bit, Ubuntu x86 64-Bit |
Native USB 3.2 Gen 2 (10Gbps) | 4 ports |
Native USB 2.0 (480Mbps) | 1 port |
PCI Express® Version | PCIe® 5.0 |
Native PCIe® Lanes (Total/Usable) | 28 / 24 |
Additional Usable PCIe Lanes from Motherboard | X870E: 8x Gen4, X870: 4x Gen4, X670E: 12x Gen4, X670: 12x Gen4, B650E: 8x Gen4, B650: 8x Gen4 |
NVMe Support | Boot, RAID0, RAID1, RAID5, RAID10 |
System Memory Type | DDR5 |
Memory Channels | 2 |
Max. Memory | 192 GB |
System Memory Subtype | UDIMM |
Max Memory Speed | 2x1R DDR5-5600, 2x2R DDR5-5600, 4x1R DDR5-3600, 4x2R DDR5-3600 |
ECC Support | Yes (Requires motherboard support) |
Graphics Model | AMD Radeon™ Graphics |
Graphics Core Count | 2 |
Graphics Frequency | 2200 MHz |
USB Type-C® DisplayPort™ Alternate Mode | Yes |
Product ID Boxed | 100-100000662WOF |
Product ID Tray | 100-000000662 |
Supported Technologies | AMD EXPO™ Technology, AMD Ryzen™ Technologies |
Warranty | 3 Years |
