MWE Gold 1250 -V2 brings optimal performance for a classic configuration. The MWE Gold 1250 -V2 power supply features virtue of 80 PLUS Gold efficiency, fully modular cabling, and a 140mm silent fan, fully support ATX3.0 with 600W 12VHPWR connectors. Together, Cooler Master provides the power supply complete with high efficiency and reliability to improve your PC experience.
Cooler Master took the initiative and continuously developing our first ATX 3.1 Power Supply lineup. Compliant with ATX 3.1 standard and 12V-2x6 connectors, the MWE Gold 1050/1250 V2 ATX 3.1 can fully support the peak power drawn by the 40 series RTX graphic cards and whole system.
The 80 PLUS Gold certification guarantees a minimum efficiency of 90%.
MWE Gold 1250 – V2 has delivered to a premium high air flow and long life bearing fan, offering more effective cooling performance.
12VHPWR connector with a compact 12+4 pin cable can pump up to 600W of power to a GPU via a single cable.
MWE Gold - V2 comes with fully modular flat, black cables for increased airflow.
Model | MPE-C501-AFCAG-3E |
ATX Version | ATX Rev. 3.1 |
PFC | Active PFC |
Input Voltage | 100-240V |
Input Current | 15-7A |
Input Frequency | 50-60Hz |
Dimensions (L x W x H) | 180 x 150 x 86 mm |
Fan Size | 140mm |
Fan Bearing | Two Ball Bearing |
Efficiency | ≥90% @ Typical Load |
80 PLUS Rating | 80 PLUS Gold |
ErP 2014 Lot 3 | Yes |
Operating Temperature | 0-50°C |
Power Good Signal | 100 - 150 ms |
Hold Up Time | ≥16ms at 100% Load |
MTBF | >100,000 Hours |
Protections | OVP / OPP / SCP / OCP / UVP / OTP / Inrush Protection |
Regulatory | TUV, cTUVus, CE, FCC, BSMI, CCC, EAC, RCM, UKCA, BIS |
ATX 24 Pin Connectors | 1 |
EPS 4+4 Pin Connectors | 1 |
EPS 8 Pin Connector | 1 |
SATA Connectors | 12 |
Peripheral 4 Pin Connectors | 4 |
PCI-e 6+2 Pin Connectors | 3 |
12V-2x6 Connectors | 1 |
Series | MWE Gold Series |
Category | Above 750W |
Modular | Fully Modular |
80 Plus Efficiency | Gold |
Form Factor | ATX |
Watts | 1250W |
