A flexible platform for a powerful ATX build that wastes no space
Features
Define Series sound dampening with ModuVent™ technology
Optimized for high airflow and silent computing
Side and front panels are lined with industrial-grade sound dampening material
Smaller than the usual ATX case, the Define C and its optimized interior provides the perfect base for users of all kinds. The open air design offers unobstructed airflow across your core components with high performance and silent computing in mind at every step.
Define Series sound dampening with ModuVent™ technology for silent operation in a compact micro ATX form factor
Optimized for high airflow and silent computing
Side and front panels are lined with industrial-grade sound dampening material
Flexible storage options with room for up to five drives
Comes with two preinstalled Fractal Design Dynamic X2 GP-12 120 mm fans optimized to deliver maximum airflow while still maintaining a low noise level
Open air designed interior creates an unobstructed airflow path from the front intake to the rear exhaust
Power supply shroud conceals drive cage and excess cabling for an even quieter and cleaner looking interior free of airflow obstructions
Includes optional top filter to prevent dust buildup when ModuVent is removed for additional fan slots
Easy-to-clean high airflow nylon filters on the front and base with full PSU coverage and front access for convenience
Specifications
3.5"/2.5" Drive Bays | 2 |
Dedicated 2.5" Drive Bays | 3 (max thickness: 10 mm) |
Expansion Slots | 7 |
Total Fan Mounts | 7 |
Front Fan | 3x 120 mm or 2x 140 mm (1x Dynamic X2 GP-12 included) |
Top Fan | 2x 120/140 mm |
Rear Fan | 1x 120 mm (1x Dynamic X2 GP-12 included) |
Bottom Fan | 1x 120 mm |
Front Radiator | 120/240/360 mm or 140/280 mm (max width: 144 mm) |
Top Radiator | 120/240 mm (max motherboard component height: 40 mm) |
Rear Radiator | 120 mm (max width: 125 mm) |
I/O Ports | 2x USB 3.0, Audio In/Out, Power Button w/ LED, HDD Activity LED, Reset Button |
Dust Filters | Bottom fan + PSU, Front fans, Top (optional) |
Cable Routing Grommets | Yes |
Fixed Velcro Straps | Yes |
Captive Thumbscrews | Right side panel, SSD brackets |
Left Side Panel | Industrial sound-dampened steel |
Right Side Panel | Industrial sound-dampened steel |
PSU Type | ATX |
PSU Max Length | 175 mm |
Motherboard Compatibility | ATX / mATX / ITX |
GPU Max Length | Max 315 mm (with front fan installed) |
CPU Cooler Max Height | 172 mm |
Cable Routing Space | 15–35 mm |
Case Dimensions (LxWxH) | 399 x 210 x 440 mm |
Case Dimensions (with extras) | 413 x 210 x 453 mm |
Net Weight | 7.4 kg |
Package Dimensions (LxWxH) | 542 x 305 x 493 mm |
Package Weight | 7.81 kg |
Volume | 36.9 Liters |
Warranty | 2 Years |
Package Contents | Define C Computer Case, User Manual, Accessory Box, Optional Top Filter |
EAN | 7.35004E+12 |
UPC | 8.17301E+11 |
Product Code | FD-CA-DEF-C-BK |
