Terra is a PC case designed and engineered to reshape the small form factor gaming experience. Inspired by the homes of modern gamers, Terra incorporates boutique design features such as thick panels cut from anodized aluminum, CNC-milled details and FSC-certified solid walnut. Inside, it includes a PCIe 4.0 riser cable and features a stepless slidable central wall for build flexibility, providing space for a powerful GPU up to 322 mm in length.
Features
Install your choice of powerful GPU up to 322 mm in length, in a space-saving 10.4 L case (excluding feet)
Add natural materials to your setup with a front-facing panel cut from FSC-certified solid walnut
Enjoy a sleek anodized aluminum exterior including an 8 mm-thick aluminum front
Add natural materials to your setup with a front-facing panel cut from FSC-certified solid walnut
Enjoy a sleek anodized aluminum exterior including an 8 mm-thick aluminum front
Make the most of natural airflow through the ventilated top, side and bottom panels
Experience powerful, uncluttered gaming, with the ability to install a GPU up to 322 mm long in a space-saving 10.4 L case (excluding feet)
Get a head start on your build with the included PCIe 4.0 riser cable
Store up to two SSDs in the dedicated 2.5” drive mounts
The Terra is available in your choice of three distinct anodized aluminum versions to perfectly complement and elevate your gaming space
Find your build’s ideal balance with 30 mm of internal flexibility provided by a stepless, movable central wall
Slide to strike the best ratio for your build, adapting the space for CPU cooling on one side and graphics card width on the other
Enjoy a naturally unique finish, with an individual front panel cut from solid walnut
Specifications
Dedicated 2.5" Drive Mounts | 2 (included) |
Expansion & Cooling |
Expansion Slots | 3 (Max GPU Mode), 2 (Max CPU-Cooler height mode) |
Total Fan Mounts | 1x 120 mm |
Bottom Fan | 1x 120 mm |
Radiator Support |
Side Radiator | 1x 120 mm (121 mm wide if GPU ≤ 200 mm and no SSDs installed) |
I/O Ports | 1x USB 3.2 Gen 2x2 Type-C (20 Gbps), 1x USB 3.0 Type-A (5 Gbps), Power button |
Build & Design |
Tool-less Panels | Push-to-lock on both side panels and top panel (optional locking with screws) |
Compatibility |
Motherboard Compatibility | Mini-ITX |
PSU Type | SFX / SFX-L |
PSU Max Length | 130 mm |
GPU Max Length | 322 mm |
GPU Max Width (if GPU H <131mm) | 72 mm (Max GPU) / 43 mm (Max CPU-Cooler) |
GPU Max Width (if GPU H 131–145mm) | 62 mm (Max GPU) / 33 mm (Max CPU-Cooler) |
GPU Max Height | 145 mm (Max GPU) / 131 mm (Max CPU-Cooler) |
CPU Cooler Max Height | 48 mm (Max GPU) / 77 mm (Max CPU-Cooler) |
Adjustable Motherboard Spine | Yes – affects allowable GPU width vs. CPU cooler height trade-off |
SFF-Ready GeForce GPU Support | Yes |
BIOS Note | Set PCIe slot to Gen4 in BIOS if using Terra PCIe 4.0 riser with PCIe 5.0-compatible hardware |
Dimensions & Weight |
Case Dimensions (L x W x H) | 343 x 153 x 218 mm |
Case Dimensions (w/o feet) | 343 x 153 x 198 mm |
Package Dimensions | 394 x 215 x 292 mm |
Net Weight | 3.1 kg |
Gross Weight | 4.0 kg |
Volume | 10.4 liters (excluding feet), 11.4 liters (external) |
Other |
Package Contents | Case, Accessory box, Manual |
SKUs | Graphite: FD-C-TER1N-01 |
EAN | Graphite: 7340172703983 |
UPC | Graphite: 843276103989 |
JAN | Graphite: 4537694302722 |
Warranty | 2 Years |
