Key Features:
Powered by the NVIDIA Blackwell architecture and DLSS 4
Powered by GeForce RTX™ 5080
Integrated with 16GB GDDR7 256bit memory interface
WINDFORCE cooling system
The WINDFORCE cooling system delivers exceptional thermal performance through a combination of cutting-edge technologies. It features server-grade thermal conductive gel, innovative Hawk fans with alternate spinning, composite copper heat pipes, a large vapor chamber, 3D active fans, and screen cooling.
Drawing inspiration from water, the back panel's ripples evoke flowing water, with mirrored, frosted, and light elements reflecting the water's shimmering surface. Metal craftsmanship refines the texture, while teal and iridescent hues accentuate the serene lake. The fan's rotation creates expanding ripples, infusing natural movement into the details.
GIGABYTE offers the best power supply solutions for your graphics cards. You can choose either the AORUS series or the UD series to power your graphics card.
GIGABYTE CONTROL CENTER (GCC) is a unified software for all GIGABYTE supported products. It provides an intuitive interface that allows users to adjust clock speed, voltage, fan mode and power target in real-time.
Key Features:
Powered by the NVIDIA Blackwell architecture and DLSS 4
Powered by GeForce RTX™ 5080
Integrated with 16GB GDDR7 256bit memory interface
WINDFORCE cooling system
Hawk fan
Server-grade thermal conductive gel
RGB Lighting
Dual BIOS (Performance / Silent)
NVIDIA SFF-ready
Reinforced structure
Versatile VGA holder
Specification:
Graphics Processing | GeForce RTX™ 5080 |
Core Clock | 2730 MHz (Reference: 2617 MHz) |
CUDA® Cores | 10752 |
Memory Clock | 30 Gbps |
Memory Size | 16GB |
Memory Type | GDDR7 |
Memory Bus | 256 bit |
Card Bus | PCI-E 5.0 |
Digital max resolution | 7680 x 4320 |
Multi-view | 4 |
Card size | L=304 W=126 H=50 mm |
PCB Form | ATX |
DirectX | DirectX 12 API |
OpenGL | OpenGL 4.6 |
Recommended PSU | 850W |
Power Connectors | 16 pin*1 |
Output | DisplayPort 2.1b x3 |
| HDMI 2.1b x1 |
Accessories | 1. VGA manual |
| 2. Warranty notice |
| 3. 1x 12V-2x6 to 3x PCIe 8pin adapter |
| 4. Versatile VGA holder |
| 5. Versatile VGA holder manual |
