A worthy choice for your PC upgrade
GIGABYTE Gen3 2500E SSD adopts Phison's controller and high-quality 3D NAND, delivers up to 2400 MB/s sequential read and 2000 MB/s sequential write performance. By utilizing Host Memory Buffer technology, the SSD controller can access the host DRAM without performance loss. Furthermore, GIGABYTE Gen3 2500E SSD features TRIM, SMART, and Over-Provision support to secure your data and perform stably.
Power Saving While Operating
Comparing with regular PCIe 3.0 x4 SSD, GIGABYTE Gen3 2500E SSD reduces about 40%+ power while operating. Power consumption of the GIGABYTE Gen3 2500E SSD is notably improved.
SSD Tool Box
The newly updated SSD Tool Box is a software that gives users an overview of the SSD Status and various aspects such as model name, FW version, health condition and sensor temperature. Moreover, users can clear all the data with the Secure Erase function. You can download the SSD Tool Box from the link.
Error Recovery Technology
The GIGABYTE exclusive technology uses special algorithm to enable Intelligent NAND Flash management, and enhance decoding capability. This optimize error recovery in NAND flash for superior storage reliability.
Media Scan
GIGABYTE exclusive Media Scan technology can automatically monitor the health status of NAND flash in the background and handle unhealthy flash blocks without disrupting regular operation.
KEY FEATURES
Form Factor: M.2 2280
Interface: PCI-Express 3.0 x4, NVMe 1.3
Total Capacity: 2000GB*
Sequential Read Speed : up to 2400 MB/s**
Sequential Write speed : up to 2000 MB/s**
HMB (Host Memory Buffer) supported
TRIM & S.M.A.R.T support
Energy-Efficient
SPECIFICATIONS
Interface | PCIe 3.0x4, NVMe1.3 interface |
Form Factor | M.2 2280 |
Total Capacity | 2000GB |
External DDR Cache | N/A |
Sequential Read speed | Up to 2400 MB/s |
Sequential Write speed | Up to 2000 MB/s |
Dimension | 22 x 2.3 x 80 mm |
Mean time between failure (MTBF) | 1.5 million hours |
Max. Operating Power | Read: 2300mW |
Max. Operating Power | Write: 2250mW |
Power Consumption (Idle, PS3) | 30mW |
Power Consumption(PS4, L1.2) | 5mW |
Temperature (Operating) | 0°C to 70°C |
Temperature (Storage) | -40°C to 85°C |
Warranty | 1. Limited 5 years or 480TBW. |
| 2. Limited warranty based on 5 years or 480TBW, whichever comes first. (*TBW is evaluated by JEDEC workload standard. ) |
| *TBW (Terabyte Written): Terabytes Written is the total amount of data that can be written into a SSD before it is likely to fail. |
| 3. When the usage of an NVME SSD as indicated by the "Percentage Used" (SMART ID: 05) in SMART page of "GIGABYTE SSD toolbox" reaches 100 means out of warranty. (A new unused product will show the number of 0) |
