GIGABYTE motherboards bundle several useful and intuitive software to help users control every aspect of the motherboard and provide customizable lighting effects with outstanding aesthetics to fit your unique personality.
DIY Friendly
Q-Flash Plus
PCIe EZ-Latch
Unlock the latch of the PCIe slot easily when removing the graphics card in the PCIe slot.
Cleaner and more efficient power delivery to the CPU with better thermal performance ensures stability under high CPU frequencies and heavy loading. - 6+1+1 Phases Low RDS(on) MOSFETs - Solid capacitors to improve transient response and minimize oscillation - 8-pin Solid Pin CPU Power Connector
PCIe 4.0 Design | Single 32GB Support | Smart Fan 6 | Hybrid Core Optimization
The maximum memory capacity on the H610 motherboard is 64 GB. After Intel updated the memory reference code, a single slot can support up to 32GB. Therefore, with populated 2 DIMM per channel on both channels, total memory capacity is 64GB, which was only available on High-End Desktop (HEDT) platforms. For users who always run out of memory capacity, there is more bandwidth now for memory-intensive applications such as rendering and video editing.
High Current Support Each fan header supports PWM and DC fan and Water cooling Pump, and up to 24W (12V x 2A) with Over-Current Protection
Precision Control Up to 7 temperature/fan speed control points for precise fan curve
Dual Curve Mode Slope/Stair dual mode for different user scenarios
Fan Stop Fan can stop completely below users' specified temperature point
With new Intel Hybrid technology, GIGABYTE exclusively creates two new "CPU Upgrade" in BIOS profiles to meet different users’ scenarios by adjusting P-Core and E-Core activation and voltage policy.
Gaming GbE LAN | PCIe 4.0 M.2 Slot | Hi-Fi Audio
High-Speed Gigabit LAN with Automatic Bandwidth Allocation Realtek 8118 LAN is a high-performance and friendly network chip for gaming players with automatic bandwidth allocation to ensure the highest network priority of the game or application. It can provide users with the most comprehensive features and the fastest and smoothest Internet experience.
GIGABYTE Motherboards are focused on delivering M.2 technology to enthusiasts who want to maximize their system’s potential.
GIGABYTE motherboards use high-end audio capacitors. These high-quality capacitors help deliver high-resolution and high-fidelity audio to provide the most realistic sound effects for gamers.
GIGABYTE motherboards feature an audio noise guard that essentially separates the board’s sensitive analog audio components from potential noise pollution at the PCB level.
Solid Pin | Anti-Sulfur
H610 motherboards feature solid plated ATX 12V 8-pin power connectors to offer a stable power supply during CPU overloading.
Larger contact area for electricity
More metal quantity to sustain higher power and generated heat
Ultra durable and longer lifespan
BIOS | APP Center | Easy Tune | System Information Viewer
The BIOS is essential for users during initial setup to allow for the most optimal settings. With a new GUI and easier-to-use functionalities, GIGABYTE has been able to reinvent the BIOS to give users a better experience while setting up their new system.
GIGABYTE APP CENTER is a useful portal of all GIGABYTE MB utilities and drivers. You can choose any utility you want to install from APP CENTER and keep updated with the latest utilities and drivers version.
GIGABYTE's EasyTune™ is a simple and easy-to-use interface that allows users to fine-tune their system settings or adjust system and memory clocks and voltages in a Windows environment.
GIGABYTE System Information Viewer is a central location that gives you access to your current system status. Monitor components such as the clocks and processor, set your preferred fan speed profile, create alerts when temperatures get too high or record your system's behavior; these are the possibilities of the System Information Viewer.
attribute | value |
|---|
CPU | 1. LGA1700 socket: Support for the 14th, 13th, and 12th Generation Intel® Core™, Pentium® Gold and Celeron® Processors* |
2. L3 cache varies with CPU | |
* Please refer to "CPU Support List" for more information. | |
Chipset | 1. Intel® H610 Express Chipset |
Memory | 1. Support for DDR4 3200/3000/2933/2666/2400/2133 MT/s memory modules |
2. 2 x DDR4 DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity) of system memory | |
3. Dual channel memory architecture | |
4. Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) | |
5. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules | |
6. Support for Extreme Memory Profile (XMP) memory modules | |
(Please refer "Memory Support List" for more information.) | |
Onboard Graphics | Integrated Graphics Processor-Intel® HD Graphics support: |
1. 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz | |
(Graphics specifications may vary depending on CPU support.) | |
Audio | 1. Realtek® Audio CODEC |
2. High Definition Audio | |
3. 2/4/5.1/7.1-channel | |
You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings. | |
LAN | 1. Realtek® GbE LAN chip (1 Gbps/100 Mbps) |
Expansion Slots | 1. 1 x PCI Express x16 slot, running at x16 |
* For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. | |
(The PCI Express x16 slot conforms to PCI Express 4.0 standard.) | |
2. 1 x PCI Express x1 slot | |
(The PCI Express x1 slot conforms to PCI Express 3.0 standard.) | |
Storage Interface | Chipset: |
1. 1 x M.2 connector (Socket 3, M key, type 2260/2280 PCIe 3.0 x4/x2 SSD support) | |
2. 4 x SATA 6Gb/s connectors | |
USB | Chipset: |
1. 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header) | |
2. 4 x USB 2.0/1.1 ports on the back panel | |
Chipset+USB 2.0 Hub: | |
1. 4 x USB 2.0/1.1 ports available through the internal USB headers | |
Internal I/O Connectors | 1. 1 x 24-pin ATX main power connector |
2. 1 x 8-pin ATX 12V power connector | |
3. 1 x M.2 Socket 3 connector | |
4. 4 x SATA 6Gb/s connectors | |
5. 1 x CPU fan header | |
6. 2 x system fan headers | |
7. 1 x RGB LED strip header | |
8. 1 x front panel header | |
9. 1 x front panel audio header | |
10. 1 x USB 3.2 Gen 1 header | |
11. 2 x USB 2.0/1.1 headers | |
12. 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only) | |
13. 1 x serial port header | |
14. 1 x Clear CMOS jumper | |
Back Panel Connectors | 1. 1 x PS/2 keyboard port |
2. 1 x PS/2 mouse port | |
3. 1 x D-Sub port | |
4. 2 x USB 3.2 Gen 1 ports | |
5. 4 x USB 2.0/1.1 ports | |
6. 1 x RJ-45 port | |
7. 3 x audio jacks | |
I/O Controller | 1. iTE® I/O Controller Chip |
H/W Monitoring | 1. Voltage detection |
2. Temperature detection | |
3. Fan speed detection | |
4. Overheating warning | |
5. Fan fail warning | |
6. Fan speed control | |
* Whether the fan speed control function is supported will depend on the cooler you install. | |
BIOS | 1. 1 x 256 Mbit flash |
2. Use of licensed AMI UEFI BIOS | |
3. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 | |
Unique Features | 1. Support for APP Center |
* Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. | |
@BIOS | |
Ambient LED | |
EasyTune | |
Smart Backup | |
System Information Viewer | |
2. Support for Q-Flash | |
3. Support for Xpress Install | |
Bundle Software | 1. Norton® Internet Security (OEM version) |
2. LAN bandwidth management software | |
Operating System | 1. Support for Windows 11 64-bit |
2. Support for Windows 10 64-bit | |
Form Factor | 1. Micro ATX Form Factor; 23.0cm x 21.5cm |
