It supports the latest PCIe Gen4x4 with up to 3500/3000 MB/s, offering superior performance which is 7 times faster than typical SATA SSD, while also downward compatible with PCIe 3.0 specification.
The use of patented ultra-thin graphene heat spreader provides the best thermal conductivity material and assembly flexibility, allowing gamers to easily DIY on their own, and any motherboard heat spreader can be supported without interference.
Supporting SLC Cache technology and smart algorithm management mechanism can help ensure operational efficiency and maximize the performance of SSD. It is a reliable and trustworthy choice for data storage.
By supporting the latest NVMe specification and optimizing the work division mechanism of NVM Sets and PLM (Predictable Latency Mode), it can effectively reduce latency time and the write loss and improve the QoS of the system. The use of the latest RRL (Read Recovery Level) technology can also improve the service life of SSD.
TEAMGROUP provides an exclusive SSD smart monitoring software. It can keep track of the status of the products at any time, monitor their quality and performance, and then perform quick and easy related setup and testing.
The T-FORCE lab has conducted rigorous quality tests and provides a five-year warranty, so you can use it with peace of mind.
| attribute | value |
|---|---|
| Capacity | 2 TB |
| Dimensions | 80.0(L) x 22.0(W) x 3.7(H)mm |
| Humidity | RH 90% under 40°C (operational) |
| IOPS | 2TB Read/Write: 500K/550K IOPS Max warranty |
| Interface | PCIe Gen4x4 with NVMe |
| MTBF | 3,000,000 hours |
| Model | CARDEA Z44L M.2 PCIe Gen4 |
| Operating System | Windows 11 / 10 / 8.1 / 8 / 7 / Vista, Linux 2.6.33 or later |
| Operation Temperature | 0˚C ~ 70˚C |
| Performance | Read: up to 3500MB/s, Write: up to 3000MB/s |
| Shock | 1,500G/0.5ms |
| Storage Temperature | -40˚C ~ 85˚C |
| Terabyte Written | 1200TBW |
| Vibration | 80Hz~2000Hz/20G |
| Voltage | DC +3.3V |
| Warranty | 5-year limited warranty |
| Weight | 7g |
