Introducing the AMD Ryzen 7000 Series: Enter a new era of performance. With the cutting-edge "Zen 4" architecture, these processors redefine speed for both gamers and creators, offering unmatched power to handle any game or workflow with ease. As the pinnacle of PC processing, the AMD Ryzen 7000 Series sets the standard for performance.
Revolutionize Your Gaming Experience: With the world's most advanced desktop processor for gamers, victory on the digital battlefield becomes your focus. Equipped with high-performance "Zen 4" cores, AMD Ryzen™ 7000 Series processors boast up to 16 cores, 32 threads, boost clocks reaching 5.7GHz, and up to 80MB of cache, delivering unparalleled gaming performance.
Embrace Cutting-Edge Technologies: Whether you're rendering complex scenes, editing massive video files, or bringing architectural visions to life, AMD Ryzen™ 7000 Series processors excel. Featuring PCIe® 5.0 storage support, ultra-fast WiFi® 6E, AMD EXPO™ technology, up to 32 processing threads, and dedicated video accelerators, these processors elevate your computing experience to new heights.
Unleash Your Processing Potential: Equipped with state-of-the-art technologies, AMD Ryzen processors ensure you stay ahead in the game. AMD EXPO™ Technology simplifies memory overclocking, while DDR5 memory support enhances gaming performance. Precision Boost 2 dynamically adjusts processor frequencies for optimal performance, while Precision Boost Overdrive takes it a step further by maximizing clock speeds and enabling easy overclocking.
Empower Personalized Performance: Take control of your processing power with unlocked overclocking capabilities. Fine-tune your AMD Ryzen processor using the intuitive AMD Ryzen Master utility, tailoring it to your specific needs and preferences.
Prepare for the Future: Experience blazing-fast "Zen 4" performance with AMD Socket AM5 motherboards. Packed with cutting-edge features like high-speed DDR5 memory, PCIe® 5.0 support, AMD EXPO one-touch memory overclocking, and hyper-efficient 5nm manufacturing, AMD Ryzen 7000 Series processors ensure your PC stays ahead of the curve.
Unprecedented Gaming Performance: Elevate your gaming experience with Exclusive AMD 3D V-Cache™ Technology, offering up to 144MB of on-chip memory. Coming soon to three new AMD Ryzen 7000 Series processors, this technology delivers unparalleled gaming hardware for the ultimate gaming experience.
attribute | value |
|---|---|
AMD EXPO™ Memory Overclocking Technology | Yes |
AMD PRO Technologies | No |
AMD Ryzen™ Master Support | Yes |
Additional Usable PCIe Lanes from Motherboard | X670E - 12x Gen4, X670 - 12x Gen4, B650E - 8x Gen4, B650 - 8x Gen4 |
Architecture | Zen 4 |
Base Clock | 4.2 GHz |
CPU Boost Technology | Precision Boost 2 |
CPU Compute Die (CCD) Size | 71mm² |
CPU Socket | AM5 |
Consumer Use | Yes |
Curve Optimizer Voltage Offsets | Yes |
Default TDP | 120W |
ECC Support | Yes (Requires mobo support) |
Family | Ryzen |
Form Factor | Desktops , Boxed Processor |
Former Codename | Raphael AM5 |
Graphics Core Count | 2 |
Graphics Frequency | 2200 MHz |
Graphics Model | AMD Radeon™ Graphics |
I/O Die (IOD) Size | 122mm² |
Instruction Set | x86-64 |
L1 Cache | 512 KB |
L2 Cache | 8 MB |
L3 Cache | 96 MB |
Launch Date | 04/06/2023 |
Market Segment | Enthusiast Desktop |
Max Memory Speed | 2x1R - DDR5-5200, 2x2R - DDR5-5200, 4x1R - DDR5-3600, 4x2R - DDR5-3600 |
Max. Boost Clock | Up to 5 GHz |
Max. Memory | 128 GB |
Max. Operating Temperature (Tjmax) | 89°C |
Memory Channels | 2 |
Multithreading (SMT) | Yes |
NVMe Support | Boot , RAID0 , RAID1 , RAID10 |
Name | AMD Ryzen™ 7 7800X3D |
Native PCIe® Lanes (Total/Usable) | 28 , 24 |
Native SATA Ports | 0 |
Native USB 2.0 (480Mbps) Ports | 1 |
Native USB 3.2 Gen 1 (5Gbps) Ports | 0 |
Native USB 3.2 Gen 2 (10Gbps) Ports | 4 |
No of CPU Cores | 8 |
No of Threads | 16 |
OS Support | Windows 11 - 64-Bit Edition, Windows 10 - 64-Bit Edition, RHEL x86 64-Bit , Ubuntu x86 64-Bit |
PCI Express® Version | PCIe® 5.0 |
Package Die Count | 2 |
Precision Boost Overdrive | Yes |
Processor Technology for CPU Cores | TSMC 5nm FinFET |
Processor Technology for I/O Die | TSMC 6nm FinFET |
Product ID Boxed | 100-100000910WOF |
Product ID Tray | 100-000000910 |
Recommended Cooler | Liquid cooler recommended for optimal performance |
Regional Availability | Global |
Series | Ryzen 7000 Series |
Supported Extensions | AES , AMD-V , AVX , AVX2 , AVX512 , FMA3 , MMX-plus , SHA , SSE , SSE2 , SSE3 , SSE4.1 , SSE4.2 , SSE4A , SSSE3 , x86-64 |
Supported Technologies | AMD EXPO™ Technology , AMD Ryzen™ Technologies |
Supporting Chipsets | A620 , X670E , X670 , B650E , B650 |
System Memory Subtype | UDIMM |
System Memory Type | DDR5 |
Thermal Solution (PIB) | Not Included |
USB Type-C® DisplayPort™ Alternate Mode | Yes |
Warranty | 3 |
