Durable Performance
GIGABYTE Ultra Durable™ motherboards built with optimal components inside out provide the prime performance and timeless platform.
Easy Friendly
Innovative and intuitive hardware, software, and BIOS interface design to create your personal style.
Specification:
CPU | LGA1851 socket: Support for Intel® Core™ Ultra Processors |
LGA1851 socket: Support for Intel® Core™ Ultra Processors | |
LGA1851 socket: Support for Intel® Core™ Ultra Processors | |
Chipset | Intel® H810 Express Chipset |
Memory | Support for DDR5 6400/5600 MT/s memory modules |
2 x DDR5 DIMM sockets supporting up to 128 GB (64 GB single DIMM capacity)of system memory | |
Dual channel memory architecture | |
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) | |
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules | |
Support for Extreme Memory Profile (XMP) memory modules | |
(The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to "Memory Support List" on GIGABYTE's website for more information.) | |
Onboard Graphics | Integrated Graphics Processor-Intel® HD Graphics support: |
- 1 x DisplayPort, supporting a maximum resolution of 3840x2160@60 Hz | |
* Support for DisplayPort 2.1 version. | |
- 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz | |
* Support for HDMI 2.1 version and HDCP 2.3. | |
(Graphics specifications may vary depending on CPU support.) | |
Audio | Realtek® Audio CODEC |
High Definition Audio | |
2/4/5.1/7.1-channel | |
* You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings. | |
LAN | Realtek® GbE LAN chip (1 Gbps/100 Mbps/10 Mbps) |
Expansion Slots | CPU: |
- 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16 (PCIEX16) | |
* The PCIEX16 slot can only support a graphics card or an NVMe SSD. | |
Chipset: | |
- 1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1 (PCIEX1) | |
Storage Interface | Chipset: |
- 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) | |
- 4 x SATA 6Gb/s connectors | |
USB | Chipset: |
- 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header) | |
- 6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the internal USB header) |
